Oxygen amplifier | Custom Price

Name: Oxygen amplifier | Custom Price
SKU: 17291
Price: 500.00 USD
Availability: InStock

This oxygen amplifier is a compact and efficient device designed for medical-grade oxygen flow management. It operates on 8–15 VDC at ~12 mA and supports AC input of 110–240 V, 50/60 Hz, with a 5A/250V fuse. Measuring 142×89×28 mm and weighing just 198 g, it delivers a flow range of 0–10 L/min (up to 20 L/min optional), with high precision at ±0.01 L/min resolution. Oxygen concentration ranges from 20–96% with ±1.8% accuracy, and it supports a maximum input flow of ≥24 L/min.

Category: Valid only with Hyperbaric Chamber Purchase

These statements have not been evaluated by the Food and Drug Administration. This product is not intended to diagnose, treat, cure, or prevent any disease.

Description

Product Specification.

– Power: 8–15 VDC at ~12 mA
– Size: 142 × 89 × 28 mm; Weight: 198 g
– Flow range: 0–10 L/min (up to 20 L/min optional)
– Resolution: ±0.01 L/min; Accuracy: ±0.2 L/min or ±4%
– Oxygen concentration: 20–96%, accuracy ±1.8%
– AC Power Input: 110 V–240 V ~, 50/60 Hz, 100 VA
– Fuse: 5 A/250 V fuse, size 5 × 20 mm
– Max Flow Rate (input): ≥ 24 L/min
